PRODUCT DESCRIPTION
Get Any Color with the Arri SkyPanel S30-C LED
The Arri SkyPanel LED Light S30-C is an extremely versatile lighting tool with the ability to produce virtually any color of light. Daylight, tungsten and theatrical colors for creating the perfect effect. Use the SkyPanel as a key or fill light as well as an area space light from above. It's low profile allows it to be tucked in tight spaces. Need to take it outside or anywhere where power is limited? No problem, the SkyPanel runs on 24-36 volt battery power. The SkyPanel S30-C is a two piece system with the light head and power supply, either AC or DC. The rugged head weighs just 16.3 lbs with the AC power supply weighing 4.6 lbs. The combination junior spud allows for mounting on either baby pin 5/8" diameter or junior receiver 1 1/8" stands and clamps. The energy efficient LED engine runs on just 200W, but produces the light output of a 1K Soft Light or 3K Space Light. Color temperature is adjustable from 2,800K to 10,000K as well as plusgreen and minusgreen control. Create subtle pastels or saturated, vibrant colors with the Skypanel. The light aperture measures 14"x11.8" for a broad, even throw. As with all LEDs,the color rendering is most important and the Arri does not disappoint with a 95 CRI and 91 TLCI. With a 50,000 hr average life span, the S30-C will be a great long term lighting investment.
Includes
- SkyPanel S30- C Head
- 3m DC Cable
- S30 Power Supply
- Power Supply Rail Mount
- Standard Diffusion Panel
- Powercon Cable with Edison Plug
Specs Head
- Optical System: Soft Diffusion Panel
- Light Aperture: 645 x 300 mm / (25.4 x 11.8 inches)
- Beam Angle: 115° (Half Peak Angle)
- Weight: Manual Version: 7.4 kg (16.3 lbs)
- Weight: Pole Op Version: 9.0 kg (20 lbs)
- Handling: Aluminum Yoke, High Strength Tilt Lock
- Mounting: 16 mm / 28 mm Combo Pin (Baby 5/8 inch / Junior 1-1/8 inch Combo Pin)
- Tilt Angle: +/- 90°
- Lamphead Voltage Input: 48 V DC
- Power Consumption: 200 W Nominal, 220 W Maximum
- Lamphead Power Connection: Male 3-Pin XLR - 15 amp (Pin 1: Negative / Pin 2: Positive)
- Battery Connector: Male 4-Pin XLR - 10 Amp (Pin 1: Negative / Pin 4: Positive)
- Battery DC Voltage Range: 23 - 36 V DC
- Battery Mode Light Output: 100% of Total Output
- White Light: 2,800K - 10,000K Continuously Variable Correlated Color Temperature
- Colored Light: Full RBG+W Color Gamut with Hue and Saturation Control
- Color Temperature Tolerance: +/- 100 K (nominal), +/- 1/8 Green-Magenta (nominal)
- Color Rendition: CRI Average > 95
- TLCI Average > 91
- Green-Magenta Adjustment: Continuously Adjustable (Full Minusgreen to Full Plusgreen)
- Dimming: 0 - 100% Continuous
- Control: On-Board Controller, 5-Pin DMX In and Through, EtherCon LAN Network Connectivity, USB-A
- Remote Device Management(RDM*): DMX Setup, Hour Counter and Standard RDM Commands
- Software Interface Ethernet: DMX Setup, Fixture Status and Firmware Upgrade Through PC, Mac USB-A: Software upgrade via flash drive
- Housing Color: Blue/Silver
- Ambient Temperature Operation: -20 - 45°C (-4 - 113°F)
- Protection Class: IP 20
- Estimated LED Lifetime (L70): 50,000 hours
- Estimated Color Shift Over Lifetime: < 200 K
- Certifications: CE, FCC; GS, cNRTL, CB
Specs Power Supply
- Power Supply Unit: S30 PSU
- Power Supply Input Range: 110- 240 V AC, 50/60 Hz
- Power Supply Output Range: 48 V DC
- Power Input Connection: powerCON TRUE1 (Bare Ends / Schuko / Edison Cables Available)
- Power Output Connection: Female 3-Pin XLR - 10 Amp (Pin 1: Negative / Pin 2: Positive) powerCON TRUE1 (mains power through)
- Weight: 2.1 kg (4.6 lbs.)
- Dimension: 383 x 116 x 90 mm (15 x 4.6 x 3.5 inch)
- Control: On-Board On/Off Switch
- Mounting: Super Clamp Attachment / SkyPanel PSU Rail Mount
