Lex Products 400a 3 Phase Cam Spider Box

PRODUCT DESCRIPTION

Lex Products 400a 3 Phase Cam Spider Box

This spider box is fed by a generator or panel and splits off five separate sets of 5 wire Cam-type receptacles. It allows multiple areas on a construction site or multiple film shots to be set up and used as needed over the course of a day. The runs are not used simultaneously and there is no overcurrent protection.

Specifications

• Rating: 400 Amp, 3 Phase (H,H,H,N,G), 4 Pole, 5 Wire, 120/208Y VAC
• Environmental Rating: NEMA 1 Indoor
• Input: (1) set of (5) 16 Series Cam-type color-coded panel mount inlets
• Output: (5) sets of (5) 16 Series Cam-type color-coded panel mount outlets
• Feed Thru: None
• Overcurrent Protection: None
• Overall Dimensions: 20.5" L x 11" W x 18" H
• Weight: 56 lbs.

Features & Benefits

• High-density polyethylene (HDPE) top, bottom and sides provide superior impact, weather and shock resistance
• Compact for convenient portability
• Expedient means of distributing 400 Amp, 3 Phase Cam-type cable runs

Markets Served

• Industrial, Motion Picture Filming
